Overview
Equipped with highly useful veterinary functions including veterinary information management, body mark, OB table and specialized measurement packages, DC-N3 Vet is an ideal solution for Vets, in need of a professional system built with budget constraints in mind.
PSH™ (Phase Shift Harmonic Imaging)
Purified Harmonic Imaging for better contrast resolution providing clearer images with excellent resolution and less noise.
iClear™
Gain improved image quality based on auto structure detection.
- Sharper & Continuous Edges
- Smooth Uniform Tissues
- Cleaner ‘no echo areas’
iBeam™
Permits use of multiple scanned angles to form a single image, resulting in enhanced contrast resolution and improved visualization.
Multiple Beam Formation
Maximum 4 times tasking for one transmitted beam, resulting in excellent time resolution and higher frame rate.
iScape™
Get a complete and extended view of the anatomical structure through panoramic imaging coupled with velocity indication and forward/backward scan ability making scanning much easier, smoother and more controllable.
ExFOV
Discover better diagnostic information through extended view of the anatomical structure on all convex and linear probes.
B-Steer
Your tool for deeper biopsy: allowing adjustments to the scan line to gain better visibility of the needle, nerves and small vessels.
Workflow
iStorage™/ iMeasurement™/ iReport™
iStorage: Directly transfer images and reports to PC via network cable iMeasurement & iReport: Offline PC software for user-define measurement table, calculation formula and report template.
Auto IMT (Intima-Media Thickness)
Auto measurement of anterior and posterior wall thickness providing accurate carotid status.
iTouch™
Gain instant auto image optimization in B, Color and PW Modes on the click of a single key.
iZoom™
Gain instant full screen view on the click of a single key.
Professional Package for Veterinary Use
- Veterinary information management
- Veterinary body mark
- Veterinary comments
- Veterinary OB table
- Specialized measurement and analysis packages for different animals
iStation™
Mindray’s unique Patient Information Management System allowing you to integrate, review, archive and retrieve patient data effectively.
Raw Data
Enables optimum flexibility for post processing of the stored images including parameter adjustments, adding comments and measurements, allowing maximum productivity during scanning.
Ergonomics
- 180orotatable HD monitor
- User-programmable keys
- Built-in battery
- Height adjustable and swiveling control panel
- USB ports and CD/DVD-ROM
- Four transducer connecters
Convex
3C5A
Center Frequency: 3.5MHz
6C2
Center Frequency: 6.5MHz
Linear
7L4A
Center Frequency: 7.5MHz
L14-6
Center Frequency: 10MHz
Phased array
2P2
Center Frequency: 2.5MHz
